250mm Silenced EC Mixed Flow Fan c/w Speed controller - 1808 Cubic Metres Per Hour

250mm Silenced EC Mixed Flow Fan c/w Speed controller - 1808 Cubic Metres Per Hour

  • $725.00



250mm Silenced EC Mixed Flow Fan c/w Speed controller - 1808 Cubic Metres Per Hour

- Soft start 150 watt 6 Pole brushless EC motor

- 1808 Cubic Metres Per Hour

- 502 Litres Per Second

- 0 to 100% Speed adjustable on remote removable lead

- Fire proof Acoustic Cotton

- Static pressue 500Pa

- Noise 55 dBA at max speed 3200rpm

- Pre-wired 230V lead & Plug

- Powder coated steel housing with Aluminum Flanges

Mixed flow fans allow air to flow in axial and radial direction in relation to the shaft. These powerful inline mixed flow fans have been designed to produce higher working pressures for applications that require higher airflows These fans are widely used in many applications, It is common to find them on duct systems, which are characterized by high pressure, good air flow with low relative noise levels. These fans are mountable at the beginning, the middle and the end of the duct system. Installation of this type of fan is simple, and so is the removal.
